Conveyor Belt Vulcanization Joint Machine(also called Rubber Conveyor Belt Vulcanizer) is dependable, lightweight and portable machine. The main parts of the conveyor belt vulcanization joint machine are made of high-strength aluminum alloy. The whole integrated heating blanket is used to heat up, with stable work, high thermal efficiency, uniform temperature, equipped with light automatic electric control box, pressure system supply 0MPa-2.0MPa, uniform pressure, easy operation, light handling, widely used in the vulcanization joint and repair of various rubber conveyor belt in metallurgy, mining, cement, power plant, port, building materials, chemical and other industries.
| Function | Conveyor Belt Hot Vulcanization Joint |
| Application | Rubber Belt Splicing |
| Material | Aluminium |
| Pressure | As our experience, normal setting is 0.8Mpa; 1.2Mpa is for EP belts; 1.4Mpa is for steel cord belts. (Max. 1.8Mpa, Adjustable) |
| Heating Way | Flexible Silicone Electric Heating Max. 200℃, Adjustable |
| Vulcanizing Temperature | 145℃ |
| Cooling Way | Built-in Water Circulation Cooling |
| Cooling Time from 145℃ to 75℃ | ≤10minutes |
| Belt Width | 650~3000mm |
| Platen Length | 780~3250mm |
| Bias Angle | 16°, 18°, 20°, 22°, 90° etc. |
| Voltage | 380V, 220V, 380V, 400V, 415V, 440V, 480V, 525V, 660V, etc. 50HZ/60HZ |
| Total Weight | 208~3200KG |
| Price | Negotiable |
| Place of Origin | Qingdao City, China |
| Brand Name | XINGHE KEER |
| Certification | CE, ISO |
| Packaging and Transport Way | Plywood Box by Sea |
| Minimum Order Quantity | 1 Set |
| Supply Capacity | 50 Sets Per Month |
| Payment Terms | T/T |
| Delivery Time | 3 ~4 Weeks |
| Warranty | 12 Months |
Notes:
Before placing an order, please confirm
Conveyor Belt Max. Width;
Splice Length;
Bias Angle;
Vulcanization Pressure;
Local Working Voltage.
● We test running the vulcanizers before delivery to find out any potential fault.
● We can record videos in English to provide sales and after-sales services.
● We offer OEM service. Your logo can be printed on conveyor belt vulcanizers.
A=Length of Platen Along the Belt
B=Width of Platen Across the Belt on the Bias
C=Right Angle Dimension across the Belt, Plus Edge Overlap
D=Bias Angle (0°/18°/20°/22° etc.)
E=Max Splice Length
We offer an extensive range of conveyor belt vulcanization joint machine, conveyor belt repair machine & electric pickling machine that are perfectly suited for a variety of mining machine operating environments
