Conveyor belt winder has the characteristics of high efficiency, strong adaptability, good terrain adaptability, convenient loading and unloading, reliable operation, safety and economy, and is widely used in various industrial fields and scenes. It has a strong ability to transport materials and can efficiently complete the transportation of a large number of materials. Conveyor belt conveyor lines can be adapted to different terrain, including curvature in space and horizontal planes. In this way, materials can be transported in areas with complex terrain or crowded areas in the plant to avoid interference by external factors such as roads, railways and rivers. The running energy consumption of the conveyor belt winder is low, and the maintenance is simple and the maintenance cost is low, which makes it have good economy in long-term use.
| Conveyor Belt Winder Specifications | |
| Max Belt Width | 2100mm |
| Max Reel Diameter | 4500mm |
| Max Reel Weight | 30 Tons |
| Max Reeling Speed | 10 RPM |
| Electrical Motor Power | 9.2 kW |
| Motor Voltage | 480 VAC |
| Equipment Dimensions | |
| Max Length | 6000mm |
| Max Width | 4500mm |
| Max Height | 2500mm |
| Max Weight | 3.5 Tons |
| Smart Control; Variable Speed; Hydraulic Drive; Hydraulic Fluid Chamber; Two Auxiliary Rollers; High Carbon Steel Frame. | |
| Notes: The small, medium and large conveyor belt winders can be delivered to your designated port by containers or super high containers. According to the working conditions, you can adopt the method of anchor bolt fixing or concrete pouring the inside of frame base to achieve stable belt pulling and winding. | |
We offer an extensive range of conveyor belt vulcanization joint machine, conveyor belt repair machine & electric pickling machine that are perfectly suited for a variety of mining machine operating environments
