High flexibility: The conveyor belt winch can be easily installed and moved according to different working requirements. It does not require complex fixed facilities, giving you the flexibility to adjust your work location.
High stability: The equipment is made of high strength carbon steel square pipe and advanced technology, with good durability and stability. Whether it is continuous work or intermittent high-intensity work, it can maintain stability and provide protection for your production.
Energy saving and environmental protection: Conveyor belt winches have high energy efficiency and can significantly reduce energy consumption. At the same time, the noise and vibration generated during the working process are also low, achieving a green and environmentally friendly working environment.
Intelligent control system: The conveyor belt winch is equipped with an advanced intelligent control system, which can achieve accurate conveyor belt speed control.
Auxiliary winch can be used together with large conveyor belt winding machine to be more flexible and more efficient.
| Model | Rated Pulling Force (KN) | Rated Speed | Rope Capacity (m) | Wire Rope | Motor Type Diameter | Motor Power (KW) | Overall Dimensions (mm) | Overall Machine Weight(KG) |
| JM1 | 10 | 15 | 100 | 9.3 | Y112M-6 | 3 | 620×701×417 | 270 |
| JM1.6 | 16 | 16 | 150 | 12.5 | Y132M-6 | 5.5 | 945×996×570 | 500 |
| JM2 | 20 | 16 | 150 | 13 | Y160M-6 | 7.5 | 945×1096×570 | 550 |
| JM3.2 | 32 | 9.5 | 150 | 15.5 | YZR160M-6 | 7.5 | 1430×1160×910 | 1100 |
| JM5 | 50 | 10 | 200 | 21.5 | YZR160L-6 | 11 | 1235×1230×805 | 1560 |
| JM6 | 60 | 9.5 | 250 | 24 | YZR180L-6 | 15 | 1235×1509×805 | 1800 |
| JM8 | 80 | 8 | 250 | 26 | YZR180L-6 | 15 | 2090×1475×956 | 2900 |
We offer an extensive range of conveyor belt vulcanization joint machine, conveyor belt repair machine & electric pickling machine that are perfectly suited for a variety of mining machine operating environments
